High repetition rate OPO burst-mode pulsed tunable laser has been successfully applied to PLIF flame combustion test
Posting Date：2023-09-24
Views: 797
Recently, a High repetition rate OPO burst-mode pulsed tunable laser from Beamtech Optronics Co., Ltd. has been successfully applied to PLIF flame combustion test.
The laser is an narrow linewidth OPO tunable laser, which replaces the traditional dye-tunable laser in the PLIF system. It has the advantages of small size, high intelligence, no need to change the dye. It is more convenient to operate. Besides, the Nd: YAG pumping source with high repetition rate and high energy has also made good progress.
Laser specifications
● wavelength: 205-800nm tunable, 1064nm, 532nm, 355nm, 266nm
● pulse width: ～10ns
● OPO pulse energy: 1-2mJ@283nm@20kHz-50kHz
● sub-pulse energy@10kHz:1J@1064nm, 500mJ@532nm, 270mJ@355nm, 70mJ@266nm
● sub-pulse frequency: 10kHz-1MHz可调
● Max sub-pulse: 100@10kHz，1000@100kHz，10000@1MHz
Burst-mode
PIV mode
Near field@1064nm
Laser features
● Wide wavelength tuning range to measure a variety of components
● High wavelength precision
● Compact design and intelligent control
● Adjustable nanosecond pulse width
